Indoor unit



Indoor unit of heat pump series



It can be installed in the ceiling, closet, storage room, garage, attic or basement of the room. It has the function of fresh air system. It can continuously introduce fresh air outdoors into the room so that your house will breathe.



Manufacturing Standards: Manufactured according to AHRI Stand 210-240-2008, passed the ETL performance test of the third-party American Electronic Testing Laboratory.





Product characteristics



1. R-410A refrigerant with high efficiency and environmental protection.



2. Variable speed fan motor.



3. Internal skeleton, increase chassis transverse stability, provide component installation and positioning.



4. Integrative water dish precision casting avoids the permeation of condensate at high temperature and humidity.



5. Compact structure, bi-directional installation design, not subject to site restrictions.



6. Provide vertical and horizontal installation of condensation pan and drainage interface.



7. Fully insulated sound insulation box.



8. Reserve the installation position of single-tube ultraviolet sterilizing lamp.



9. Reserve the installation position of auxiliary electric heating.



10. Self-contained return air filter device to save space.





Box characteristics



1. Armored B1 fire-proof chassis shield.



2. Removable front inspection panel.



3. Environmental protection XPE special sound insulation and heat insulation material to prevent condensation of chassis.
